Precision Drilling for Perfect, Leak-Free Outlet Drops
Take the guesswork out of system expansion with the Infinity Compact Saddle Clamp Drill Jig. Designed specifically for the Infinity Aluminum Piping System, this essential tool ensures that every hole drilled for a saddle clamp is perfectly centered and perpendicular to the pipe.
Adding new drops to your compressed air system should be fast and reliable. Without a jig, a drill bit can “walk” or enter at an angle, leading to misaligned holes that prevent the saddle clamp’s O-ring from sealing correctly. This jig guarantees professional accuracy, ensuring a 100% leak-free connection every time.
Key Features & Benefits
Perfect Alignment: The jig serves as a secure guide for your drill bit, ensuring the hole is drilled exactly in the center of the pipe. This critical precision ensures the saddle clamp O-ring sits flush against the pipe surface for a perfect seal.
Prevents Slip & Damage: Drilling into smooth aluminum pipe can be difficult as bits tend to slide. The jig locks onto the pipe, holding the drill steady and preventing accidental scratches or damage to the blue powder-coat finish.
Safe & Fast Installation: By stabilizing the drilling process, the jig reduces installation time and improves operator safety. It allows for rapid deployment of multiple drops across a facility without measuring fatigue.
Compact Design: Its low-profile design allows you to drill new outlets even in tight spaces, such as close to ceilings or walls, where air compressor piping is often routed.
How It Works
Position: Snap or slide the jig onto the Infinity pipe at the desired outlet location.
Drill: Insert the correct size drill bit through the hardened guide bushing and drill into the pipe.
