Infinity Male Threaded Connector

Infinity Male Threaded Connector (Nickel-Plated Brass & Aluminum)

The Essential Bridge Between Your Pipe and Equipment

Seamlessly integrate your Infinity piping system with your critical equipment using the Infinity Male Threaded Connector. Designed to provide a secure, leak-free transition, this connector allows you to attach Infinity tubing directly to threaded ports on air compressors, dryers, filters, and valves.

Available in both Nickel-Plated Brass (for smaller diameters) and Aluminum (for larger diameters), this fitting ensures reliable performance regardless of your system’s scale.

Two Materials, One Standard of Excellence

1. Nickel-Plated Brass (20mm – 63mm)

For standard shop distribution lines, our heavy-duty brass connectors offer unmatched robustness.

• Corrosion Protection: The nickel plating provides a tough shield against environmental corrosion and chemical exposure.
• Durability: Solid brass construction withstands mechanical stress and vibration common near compressed air equipment.
• Aesthetics: The bright, clean finish matches the professional look of the Infinity system.

2. Die-Cast Aluminum (80mm – 168mm)

For industrial mainlines and high-flow applications, our aluminum connectors provide a lightweight yet rigid solution.

• Lightweight Strength: Eliminates unnecessary weight stress on large headers and equipment ports.
• Thermal Consistency: Being made of the same material as the Infinity Aluminum Pipe, these fittings expand and contract at the same rate during temperature fluctuations, maintaining a perfect seal.
• Full Bore Flow: Engineered to maximize airflow in high-volume systems without restriction.

Key Features & Benefits

• Zero-Leak Technology: Both versions feature the patented Infinity internal seal system. The “push-to-connect” tube side creates an instant airtight lock, while the threaded side ensures a secure interface with your machinery.
• Versatile Connectivity: Perfect for starting a run from a compressor house or terminating a drop line at a regulator or manifold.
• Rapid Installation: No welding, gluing, or threading of the pipe itself is required. Simply thread the connector into your equipment and push the Infinity pipe in.
• Reusable & Modular: If you change your compressor or move equipment, the fitting can be disconnected and reused, saving money on future modifications.

Technical Specifications

• Materials:
  • Small Bore: Nickel-Plated Brass
  • Large Bore: Die-Cast Aluminum alloy
• Thread Type: NPT (National Pipe Taper) Standard
• Pressure Rating: Up to 232 PSI (16 Bar)
• Temperature Range: -4°F to +176°F (-20°C to +80°C)
• Compatible Media: Compressed Air, Vacuum, Inert Gases (Nitrogen, Argon)

Connect with confidence. Choose Infinity Male Threaded Connectors for a secure link between your air supply and your pipe network.
