Screw Beam Clamp

Infinity Screw Beam Clamp (For 3/8″ & 1/2″ Threaded Rod)

The Non-Destructive Solution for Overhead Pipe Suspension

Securely hang your Infinity Aluminum Piping System from structural steel without the need for drilling, welding, or compromising the integrity of your building. The Infinity Screw Beam Clamp is a heavy-duty mounting solution designed to grip onto I-beams, bar joists, and structural flanges, providing a solid anchor point for threaded rod suspensions.

Featuring a versatile design, choose 3/8″ and 1/2″ threaded rods, giving you the flexibility to adapt to existing hanging hardware or heavy-duty load requirements.

Key Features & Benefits

• Universal Rod Compatibility: option for 3/8″ and 1/2″ threaded rod sizes. Whether you are hanging lightweight distribution lines or heavy industrial headers, this single clamp adapts to your specific hardware needs.
• No-Drill Installation: Preserve the structural rating of your facility’s beams. The screw-clamp design tightens securely onto the flange using a set screw, eliminating the need for power tools, drilling, or welding.
• Adjustable & Reusable: Need to reroute your compressed air system? Simply loosen the set screw and slide the clamp to a new position. It is fully reusable, making it perfect for temporary setups or evolving production floors.
• Heavy-Duty Load Bearing: Constructed from malleable iron with a hardened steel set screw, this clamp is engineered to support the weight of long runs of Infinity Pipe filled with compressed air, ensuring a safe overhead environment.
• Corrosion Resistant: Finished with a zinc plating to resist rust and oxidation, ensuring long-term reliability even in unconditioned warehouse ceilings.

Technical Specifications

• Material: Malleable Iron (Zinc Plated finish)
• Threaded Rod Input: Tapped for 3/8″-16 and 1/2″-13 (Check specific model for dual-tap or specific size availability)
• Jaw Opening: Fits flanges up to 7/8″ thick (Standard)
• Set Screw: Hardened Steel Cup Point
• Application: Suspending air piping, conduit, or HVAC equipment from structural steel beams.

Ideal Applications

• High-Ceiling Warehouses: Suspending main loop headers from roof trusses.
• Industrial Plants: Clamping to steel columns to support vertical drop lines.
• Mezzanines: Running air lines beneath steel grating or flooring structures.

Build a secure, professional pipe suspension system from the top down with the Infinity Screw Beam Clamp.
