Infinity Wire Suspension Kit – 10 Pack

Infinity Wire Suspension Kit – Part 90831

The Fast, Lightweight Alternative to Threaded Rod

Speed up your installation and reduce labor costs with the Infinity Wire Suspension Kit (90831). Designed to replace heavy, cumbersome threaded rods, this professional cable hanging system allows you to suspend Infinity Aluminum Piping from high ceilings, bar joists, or beams with a fraction of the effort.

This specific kit features a 1/4-20 UNC Threaded Stud, making it the perfect match for the standard Infinity Sliding Pipe Clips (90810 Series) and Hanging Brackets (90820 Series) used on 20mm–63mm piping.

Key Features & Benefits

• 1/4″ Threaded Interface: The adjustable locking unit (Gripple-style hanger) features a built-in 1/4-20 Male stud. This screws directly into the top of your Infinity pipe clip, creating a secure, integrated connection without the need for extra nuts or washers.
• Rapid Height Adjustment:

Forget measuring, cutting, and deburring steel rods. With this system, you simply loop the cable over the structural beam, feed it through the locking unit, and pull to raise the pipe. Need to level the line? Just depress the release pin to lower it. You can level a 100ft run in minutes.

• 15-Foot Cable Length: Comes pre-packaged with a 15-foot (4.5m) galvanized steel aircraft cable, providing ample length for most warehouse and factory ceilings. Excess cable can be snipped off in seconds with wire cutters.
• Vibration Dampening: Unlike rigid threaded rod, flexible cable absorbs compressor vibration and minor building sway, reducing stress on the fittings and preventing the “rattle” often heard in hard-piped systems.
• Aesthetic Appeal: The thin, galvanized wire is nearly invisible from the floor, creating a clean, “floating” look for your air system that architects and facility managers love.

Technical Specifications

• Part Number: 90831
• Thread Size: 1/4-20 UNC (Male Stud)
• Cable Length: 15 Feet (Standard)
• Load Rating: Safe Working Load (SWL) ~100 lbs (45 kg) per hanger (Check specific data sheet)
• Compatibility:
  • Fits Infinity Strut Brackets (90810)
  • Fits Infinity Hanging Brackets (90820)
  • Note: For larger pipes requiring 3/8″ threads, use Part 90832.

How to Install

1. Wrap: Loop the wire end over the ceiling truss or beam and pass the tail through the pre-formed loop (choke knot).
2. Connect: Screw the locking unit (stud) into the Infinity Pipe Clip.
3. Insert: Feed the wire tail into the top of the locking unit.
4. Adjust: Slide the unit up the wire to the desired height. The internal cams lock it automatically.
5. Trim: Cut off the excess wire for a neat finish.

Cut your hanging time in half. Switch to the Infinity 90831 Wire Suspension Kit.
