Infinity Safety Valve Kit

Infinity Manual Lockout L-O-X Valve (Safety Series)

The “Zero Energy” Standard for OSHA Compliance

Ensure absolute safety during machine maintenance with the Infinity Manual Lockout L-O-X Valve. While standard ball valves simply block airflow, they often leave dangerous residual pressure trapped in the machine. The L-O-X (Lock-Out-Exhaust) valve is designed to fundamentally solve this by isolating the air supply and automatically exhausting downstream pressure to the atmosphere.

Based on the industry-standard design (similar to Ross Controls), this valve is the critical component for achieving a Zero Energy State. It allows maintenance crews to shut off the air, verify zero pressure, and physically padlock the valve in the “OFF” position, preventing accidental re-energization while they work.

Key Features & Benefits

• Shut-Off & Exhaust (2-in-1 Action):

Unlike a standard valve, the L-O-X valve performs two functions with one motion. When you push the handle to the “Closed” position, it blocks the incoming main supply and simultaneously opens an exhaust port to vent all downstream air. This eliminates the risk of pneumatic actuators firing unexpectedly due to trapped air.

• OSHA 29 CFR 1910.147 Compliance: Designed specifically for Lockout/Tagout (LOTO) procedures. The unique handle design includes large loops that accept a safety padlock (or a hasp for multiple locks). The valve cannot be opened until the padlock is removed, ensuring the technician is safe.
• High-Visibility Status: The valve design (often bright yellow with a red handle) provides immediate visual confirmation of the system’s state. It is easy to see from a distance whether a machine is “Live” or “Locked Out.”
• Sensing Port: Includes a threaded sensing port that allows you to install a pressure indicator or pressure switch. This provides visual verification to the operator that the downstream air has indeed been fully exhausted.
• Infinity System Integration: Features standard NPT threaded ports. It integrates seamlessly into your Infinity aluminum air line using Infinity Male Threaded Adapters.

Technical Specifications

• Function: 3-Way, 2-Position (Normally Closed)
• Operation: Manual Push/Pull or Lever Handle
• Body Material: Aluminum/Zinc with Teflon coating for corrosion resistance
• Spool Material: Stainless Steel
• Pressure Rating: Up to 150-300 PSI (Depending on specific model)
• Temperature Range: 40°F to 175°F (4°C to 80°C)
• Inlet/Outlet: Threaded NPT (Use Infinity Male Adapters to connect to tubing)

Ideal Applications

• Machine Isolation: The primary shut-off point for individual automated machines, presses, or conveyors.
• Maintenance Zones: Isolating a specific section of the plant for repair without shutting down the entire compressor system.
• Confined Spaces: Ensuring air lines entering tanks or pits are physically locked out before entry.

How It Works

1. Run Mode: Handle is pulled out. Air flows freely from inlet to outlet.
2. Lockout Mode: Handle is pushed in. Inlet is blocked. Outlet is connected to the exhaust port, venting pressure.
3. Secure: Insert a padlock through the handle loop. The system is now mechanically secured and safe for service.

Safety is not optional. Upgrade your isolation points with the Infinity Manual Lockout L-O-X Valve.
