Infinity Lockable Tube-to-Tube Ball Valve

Infinity Lockable Tube-to-Tube Ball Valve (In-Line Valve)

The Ultimate Control for Air System Isolation

Gain complete control over your compressed air network with the Infinity Tube-to-Tube Ball Valve. Designed for seamless integration into the Infinity Aluminum Piping System, this high-performance valve features built-in push-to-connect ports on both ends, allowing you to install it directly between two lengths of pipe without the need for threaded adapters or unions.

Whether you need to isolate a specific machine for maintenance, section off a plant zone, or shut down a drop leg, this valve provides a fast, leak-free, and reliable solution. Its “full-bore” design ensures that even when the valve is open, there is zero restriction to airflow, maintaining maximum pressure efficiency across your facility.

Key Features & Benefits

• Integrated Push-to-Connect Ends:

Forget screwing threaded valves into pipe adapters. This valve connects directly to the aluminum tubing. Simply push the pipe into both sides of the valve for an instant, secure seal. This significantly reduces installation time and potential leak points.

• Full-Flow Architecture: The internal ball mechanism is matched to the pipe diameter, allowing air to pass through without turbulence or pressure drop. This is critical for maintaining the efficiency of your compressor system.
• Zone Isolation & Safety: Strategically placing these valves allows you to shut off air to a single machine or department for repairs without depressurizing the entire plant. This maximizes uptime for the rest of your facility.
• Heavy-Duty Construction: Manufactured from robust nickel-plated brass, the valve body is resistant to corrosion and mechanical stress. It handles the vibration and thermal fluctuations of industrial environments far better than plastic alternatives.
• Quarter-Turn Operation: Features a sturdy, ergonomic lever handle that opens or closes the flow with a simple 90-degree turn, providing quick visual indication of the valve’s status (Parallel = Open, Perpendicular = Closed).

Technical Specifications

• Configuration: Double Union / Tube-to-Tube (In-Line)
• Material: Nickel-Plated Brass Body & Internals
• Seals: NBR (Nitrile) – Oil and Condensate Resistant
• Pressure Rating: Up to 232 PSI (16 Bar)
• Temperature Range: -4°F to +176°F (-20°C to +80°C)
• Available Sizes: 20mm, 25mm, 32mm, 40mm, 50mm, 63mm (Standard Bore)

Ideal Applications

• Main Line Sectioning: Installed at regular intervals on long headers to allow for future expansion or isolation.
• Machine Drops: Placed on the vertical drop leg before the regulator/lubricator (FRL) to allow safe servicing of pneumatic tools.
• Compressor Isolation: Installed downstream of the compressor or dryer to isolate the equipment from the storage tank.

Take command of your airflow. Install Infinity Tube-to-Tube Ball Valves for efficient, reliable system control.
