Male Threaded Elbow 14mm

Infinity 14mm Swivel Elbow (SwiftFit)

The Ultimate “Problem Solver” for Tight Connections

Navigate tight spaces and mixed thread standards with the Infinity 14mm Swivel Elbow. Designed specifically for the 14mm Infinity Tubing Series, this high-performance fitting allows you to connect a run of tubing directly into a threaded port at a precise 90° angle.

Like its counterpart the Tee, this elbow features the revolutionary “SwiftFit” Universal Thread. Whether you are connecting to an American pneumatic cylinder (NPT), a European valve bank (BSPP), or an Asian filter unit (BSPT), this single fitting seals them all securely, eliminating the need for adapters.

Key Features & Benefits

• Universal “SwiftFit” Thread: Engineered with a specialized thread geometry that screws into Female NPT, BSPP (G), and BSPT (R) ports indiscriminately. It creates a vacuum-tight seal on almost any equipment without requiring thread tape or identification gauges.
• 360° Alignment Swivel:

Threading an elbow is usually a headache—it never tightens ending up facing the right direction. This fitting solves that. The body rotates 360° independently of the thread. Simply tighten the thread fully, then rotate the elbow to point exactly where your tubing needs to go.

• Compact 90° Design: Ideal for point-of-use applications. It allows the 14mm tubing to exit the machine or valve immediately parallel to the surface, saving space and preventing the “looping” required by straight fittings.
• 14mm Push-to-Connect: Features the standard Infinity stainless steel grab-ring. Just push the 14mm tube in for an instant, permanent connection that holds firm against vibration and pressure.
• Full-Metal Durability: Constructed from heavy-duty Nickel-Plated Brass. It resists corrosion, withstands side-load stress better than plastic, and maintains the professional aesthetic of your system.

Technical Specifications

• Tubing Connection: 14mm OD Tube
• Thread Connection: Male SwiftFit (Universal NPT/BSP)
• Configuration: 90° Elbow (Swivel)
• Available Sizes:
  • 14mm x 3/8″ Male SwiftFit
  • 14mm x 1/2″ Male SwiftFit
• Pressure Rating: Up to 232 PSI (16 Bar) – Vacuum Compatible
• Temperature Range: -4°F to +176°F (-20°C to +80°C)

Ideal Applications

• Pneumatic Cylinders: Screwing directly into the cylinder port to route the air line tight against the machine body.
• FRL Units: Connecting the supply tube to the inlet of a Filter-Regulator in a confined cabinet.
• Valve Manifolds: Creating a neat, organized array of lines exiting a solenoid bank.

Eliminate adapters and alignment frustration. Streamline your machine builds with the Infinity 14mm Swivel Elbow.
