Inert Gases Aluminum Pipe for Infinity Piping System

The inert gas pipe is powder coated black to identify the gas lines from pressure or vacuum lines.

USA REF Ø Ext. Wall Thickness Max Pressure Weight Length Bag
90000BK-6-20 20 mm 0.059 (1.5) 16 Bar 235 g/m 5,95 m (0.234) 8
90000BK-6-25 25 mm 0.059 (1.5) 16 Bar 298 g/m 5,95 m (0.234) 8
90000BK-6-32 32 mm 0.059 (1.5) 16 Bar 387 g/m 5,95 m (0.234) 9
90000BK-6-40 40 mm 0.059 (1.5) 16 Bar 490 g/m 5,95 m (0.234) 4
90000BK-6-50 50 mm 0.079 (2 ) 16 Bar 814 g/m 5,95 m (0.234) 4
90000BK-6-63 63 mm 0.079 (2 ) 16 Bar 1034 g/m 5,95 m (0.234) 2
90000BK-6-80 80 mm 0.079 (2 ) 16 Bar 1283 g/m 5,95 m (0.234) 2
90000BK-6-110 110 mm 0.098 (2.5) 16 Bar 2280 g/m 5,95 m (0.234) 1
90000BK-6-168 168 mm 0.157 (4) 16 Bar 5700 g/m 5,95 m (0.234) 1

Inert Gases Aluminum Pipe

Inert gases aluminum pipe is used with all Infinity fittings. Available in diameters 20mm-168mm.

Inert Gases Aluminum Pipe Advantages

  1. Lightweight:
    • Aluminum is much lighter than other common piping materials, such as steel or copper.
    • This makes it easier to handle, transport, and install, reducing labor costs and installation time.
  2. Corrosion Resistance:
    • Aluminum naturally forms a thin oxide layer on its surface, which protects it from corrosion.
    • This makes it ideal for use in environments prone to moisture or exposure to certain chemicals.
  3. Durability:
    • Aluminum is strong yet flexible, making it resistant to cracking, bursting, or deformation under pressure.
    • Its resistance to wear and tear gives it a long lifespan in many applications.
  4. Energy Efficiency:
    • Aluminum has excellent thermal conductivity, which is beneficial for applications involving heat transfer, such as refrigeration or air conditioning.
    • Its smooth internal surface reduces pressure loss and energy consumption in compressed air systems.
  5. Cost-Effective:
    • While aluminum might have a higher upfront cost than some materials (e.g., PVC), its durability, corrosion resistance, and low maintenance requirements often result in lower long-term costs.
  6. Recyclability:
    • Infinity Inert Gases Aluminum Pipe is 100% recyclable without losing its properties, making it an environmentally friendly choice.
    • Using recycled aluminum in manufacturing saves energy compared to producing new material.
  7. Aesthetic Appeal:
    • Aluminum pipes often have a clean, professional look that requires no additional painting or coating.
    • This can be important in environments where aesthetics matter, such as commercial or visible industrial spaces.
  8. Non-Sparking and Non-Magnetic:
    • Aluminum’s non-sparking properties make it safe for applications in explosive or flammable environments.
    • Its non-magnetic properties are ideal for specific industries, such as electronics or sensitive equipment manufacturing.
  9. Resistance to Contamination:
    • Infinity Compressed Air Aluminum pipe does not rust, so it doesn’t introduce rust particles into fluid or air systems.
    • This makes it ideal for clean environments, such as food processing, pharmaceuticals, or compressed air systems.

Infinity’s all metal system makes is the ruffed long lasting market choice for compressed air systems.
