Infinity Flange Bolt Kit

Infinity Flange Bolt & Nut Kit

The Secure Fastening Solution for Industrial Flange Connections

Use M16 for either 80mm or 110mm and use M20 for the 168mm.

Ensure a rock-solid, leak-free seal on your heavy-duty industrial air mains with the Infinity Flange Bolt Kit. Designed specifically for the larger diameters of the Infinity Aluminum Piping System (80mm, 110mm, 168mm, and above), this kit provides the exact hardware needed to connect flange-to-flange sections or mount flanged butterfly valves and compressor outlets.

Using mismatching or low-grade hardware on high-pressure air systems can lead to uneven seal compression, leaks, or even joint failure. Infinity Bolt Kits take the guesswork out of installation, providing high-tensile strength fasteners that are sized perfectly for the flange thickness and bolt-hole patterns of the Infinity system.

Key Features & Benefits

• Complete Installation Set: Each kit comes pre-packaged with the necessary bolts, hex nuts, and flat washers required for a single flange connection. No more wasting time sourcing individual hardware components from the hardware store.
• High-Tensile Strength: Manufactured to industrial standards (typically Grade 8.8), these bolts are engineered to withstand the torque required to compress the gasket properly and hold against system pressures up to 232 PSI.
• Corrosion Resistant Finish: Just like your Infinity pipe, the hardware is zinc-plated to resist rust and corrosion. This ensures that maintenance or future disassembly is easy, even after years of service in humid environments.
• Precision Sizing: The bolt lengths are calculated to provide full thread engagement through the flange and nut without excessive overhang, ensuring a clean, professional installation that doesn’t interfere with insulation or nearby obstructions.

Technical Specifications

• Material: High-Tensile Steel (Zinc-Plated for corrosion resistance)
• Kit Contents: Hex Bolts, Hex Nuts, Flat Washers (Quantity varies by flange size)
• Compatibility: Designed for Infinity Aluminum Pipe Flanges & Butterfly Valves
• System Sizes Supported: 80mm (3″), 110mm (4″), 168mm (6″), 220mm (8″)
• Application: Compressed Air, Vacuum, Inert Gas

Ideal Applications

• Valve Installation: Securing wafer-style or lug-style butterfly valves between pipe sections.
• Compressor Hookups: connecting the main discharge flange of large industrial air compressors to the piping network.
• Manifold Assembly: Bolting together header sections in large plant distribution loops.

Don’t compromise your heavy industrial connections. Use genuine Infinity Flange Bolt Kits for a safe, secure, and professional assembly.
