Envirotect Oil/Water Separator – Pallet Combination

Infinity Envirotect Super Pak (Pallet Series)

The Heavy-Duty Solution for Large-Scale Condensate Management

Handle the massive condensate output of industrial compressor rooms with the Infinity Envirotect Super Pak. Designed for facilities running 200 HP to 2,000+ HP systems, this is not just a separator—it is a complete, palletized condensate processing station.

Rebranded from the industry-leading Clean Resources Super-Pak, this system eliminates the need to daisy-chain multiple smaller separators together. It arrives as a fully pre-plumbed, skid-mounted unit ready to treat high-volume discharge from large rotary screw compressors, dryers, and receiver tanks, ensuring your facility remains EPA compliant (<10 ppm oil carryover).

Key Features & Benefits

• Turnkey Palletized System: The unit comes strapped to a heavy-duty pallet (typically 48″ x 48″ for larger models), making it easy to position with a forklift. It is fully assembled, primed, and leak-tested at the factory—simply drop it in place and connect your drain lines.
• Massive Capacity (Up to 10,000 CFM): Engineered for the biggest jobs. Whether you have a centralized compressor room with multiple 100HP machines or a single massive centrifugal unit, the Super Pak handles the load without “flooding” or bypassing.
• Pre-Plumbed Manifold & Pump System: Includes a sophisticated intake system with multiple inlet ports (typically six) to accept drains from various sources. It often features an integrated active transfer pump or flow regulation system to manage the surge of condensate, preventing the “back-up” issues common in gravity-only systems.
• Advanced Media Technology: Utilizes proprietary Alumina Silicate Substrate media. Unlike activated carbon which ruins easily, this media molecularly bonds to the oil (including difficult Polyglycol and Silicone-based synthetics) while repelling water, ensuring the filter bed lasts longer and doesn’t channel.
• “Zero-Mess” Maintenance: Forget scooping sludge. The system uses a modular “change-out” design. When the media is spent, you don’t dig it out—you simply replace the specific module or drum components. It is clean, safe, and requires no special tools.

Technical Specifications

• Series: Envirotect Super Pak (matches Clean Resources Super-Pak)
• Configuration: Pallet-Mounted Multi-Bed System
• Capacity Range: 6,000 CFM to 10,000 CFM (Dependent on model 1, 2, 3, or 4)
• Oil Carryover: Guaranteed <10 ppm
• Compatibility: All compressor lubricants (Mineral, PAO, Polyol Ester, Diester, Silicone, Glycol)
• Dimensions: Ships on standard industrial pallets for easy handling.

How It Works

1. Collection: Condensate from all plant drains enters the central manifold.
2. Decompression: The system vents excess pressure to prevent turbulence in the separation bed.
3. Separation: The condensate flows through the massive media beds where oil is permanently trapped.
4. Discharge: Clean water flows out to the sanitary sewer, fully compliant with environmental regulations.

Don’t risk EPA fines on your big systems. Manage high-volume condensate efficiently with the Infinity Envirotect Super Pak.
