Envirotect Oil/Water Separator – Manifold Installed

Envirotect Oil/Water Separator (with Pre-Installed Manifold)

The “Plug-and-Play” Solution for EPA Compliance

Simplify your condensate management and ensure effortless environmental compliance with the Envirotect Oil/Water Separator, now featuring a Pre-Installed Inlet Manifold.

Compressor condensate is classified as hazardous waste. Dumping it down the drain is illegal and can result in massive EPA fines. The Envirotect system filters this waste, separating the oil from the water so you can legally dispose of the clean water in your municipal sewer. This “Manifold Installed” model takes convenience a step further by arriving ready to accept multiple drain lines immediately, eliminating the headache of building your own plumbing tree.

The “Manifold” Advantage

Standard separators often come with a single inlet port, forcing installers to spend hours piecing together PVC elbows and tees to connect all their equipment (compressors, dryers, tanks, filters).

• Ready for Action: This unit ships with a professional intake manifold already mounted.
• Multiple Inputs: Easily connect 2, 3, or 4 separate drain lines directly to the unit.
• Zero Back-Pressure: The manifold includes a diffusion chamber or relief vents (depending on model) to ensure high-pressure drain blasts don’t splash back or disrupt the separation process.

Key Features & Benefits

• Guaranteed Compliance: Reduces oil concentration in condensate to <10 ppm, far below the standard municipal limit of 15-50 ppm.
• Universal Compatibility: Works with all compressor lubricants (Mineral, Semi-Synthetic, PAO, and Polyglycol). You don’t need to buy specific “poly” models.
• Mess-Free Maintenance: Unlike old-fashioned gravity separators that require scooping messy sludge, the Envirotect uses lightweight filter cartridges. When the media is saturated, simply pull out the old bag/cartridge and drop in a new one.
• No Stagnant Water: Advanced design prevents the growth of mold and bacteria often found in settling tanks.
• Visual Indicators: Includes a test jar or sample port so you can visually verify water clarity at any time.

How It Works

1. Inlet: Condensate enters through the pre-installed manifold.
2. Expansion: The chamber depressurizes the air/water mix, allowing the liquid to settle.
3. Filtration: The mixture passes through a proprietary media bed that attracts and traps oil molecules while letting water pass through.
4. Discharge: Clean, filtered water flows out of the outlet, ready for the sewer.

Technical Specifications

• Configuration: Standalone Unit with Integrated Manifold
• Performance: <10 ppm Oil Carryover
• Media Type: Advanced Adsorption Media (Non-Carbon based options available)
• Sizing: Models available from 75 CFM up to 3,000+ CFM
• Inlet Connections: Multiple (via Manifold)
• Outlet Connection: Gravity drain to sewer

Why You Need This

If you have a compressor, a dryer, and a tank, you have at least three sources of condensate. Connecting them all to a single box can be a plumbing nightmare. The Envirotect with Manifold solves the plumbing problem and the legal problem in one box.

Protect the environment and your bottom line. Install the Envirotect Oil/Water Separator today.
