Aignep Air Distributor (Series N090)

The “Power Strip” for Your Pneumatic System

Turn a single air line into a multi-tool hub with the Aignep Air Distributor (Series N090). Designed to integrate seamlessly with the Aignep FRL Evo Series or mount independently as a wall block, this heavy-duty aluminum manifold allows you to branch off multiple auxiliary lines from a single main supply point.

Instead of cobbling together messy arrangements of tees and nipples that leak and sag, the N090 provides a rigid, professional distribution point. It is the perfect solution for creating “drop blocks” at workstations or tapping into your air preparation system to feed gauges, pressure switches, or secondary tools.

Key Features & Benefits

• Modular FRL Integration: Designed to bolt directly in-line with Aignep Filter-Regulator-Lubricator units. You can sandwich this block between a Filter and a Regulator to pull off “clean, dry air” for a blow gun, while the main stream continues on to the Lubricator for your air tools.
• Multiple Output Ports: Features 4 Distribution Ports (typically Top, Bottom, Front, and Back faces). This versatility allows you to route hoses in any direction without stressing the tubing or using swivel elbows.
• High-Flow Aluminum Body: Machined from solid aluminum alloy, ensuring it is lightweight yet capable of handling high pressure (up to 260 PSI / 18 Bar). It resists corrosion and provides a sturdy anchor point for your plumbing.
• Flexible Mounting: Can be wall-mounted using standard brackets or supported directly by the rigid piping.
• Universal NPT Threads: Features standard NPTF (National Pipe Taper Fuel) threads, ensuring compatibility with all standard US pneumatic fittings, quick couplers, and valves.

Technical Specifications

• Series: N090 (Air Distributor)
• Material: Anodized Aluminum
• Max Pressure: 260 PSI (18 Bar)
• Temperature Range: -14°F to +176°F (-10°C to +80°C)
• Configurations Available:
  • Size 1: 1/4″ or 3/8″ Main x (4) 1/8″ or 1/4″ Aux Ports
  • Size 2: 1/2″ Main x (4) 1/4″ or 1/2″ Aux Ports
  • Check specific SKU for exact port layout.

Ideal Applications

• FRL Stations: Adding a “Dry Air” port before the lubricator for paint guns or blow-off nozzles.
• Control Panels: Acting as a central header to feed multiple solenoid valves inside a cabinet.
• Sensor Mounting: Providing a convenient port to install a pressure switch or digital gauge without disrupting the main flow.

Organize your outlets and simplify your plumbing. Install the Aignep N090 Air Distributor today.
